Mũi phay 2 me corner radius G8A60

Mô tả

EDP No.	R	D1	D2	L1	L3	L2	Mill Dia. Tolerance	Shank Dia.Tolerance	No. of Flute	Taper Angle
G8A600060102	R0.10	0.6	4	0.9	2	45	0~-0.012	h5	2
G8A600070104	R0.10	0.7	4	1	4	45	0~-0.012	h5	2
G8A60008	R0.10	0.8	4	1.2	4	45	0~-0.012	h5	2
G8A600080102	R0.10	0.8	4	1.2	2	45	0~-0.012	h5	2
G8A60010	R0.20	1	6	1.5	4	50	0~-0.012	h5	2
G8A600100308	R0.30	1	6	1.5	8	50	0~-0.012	h5	2
G8A60015	R0.20	1.5	6	2.5	4	50	0~-0.012	h5	2
G8A600150206	R0.20	1.5	6	2.5	6	50	0~-0.012	h5	2
G8A600150208	R0.20	1.5	6	2.5	8	50	0~-0.012	h5	2
G8A600150306	R0.30	1.5	6	2.5	6	50	0~-0.012	h5	2
G8A600150308	R0.30	1.5	6	2.5	8	50	0~-0.012	h5	2
G8A60020	R0.50	2	6	3	10	55	0~-0.012	h5	2
G8A600200208	R0.20	2	6	3	8	50	0~-0.012	h5	2
G8A600200210	R0.20	2	6	3	10	55	0~-0.012	h5	2
G8A600200212	R0.20	2	6	3	12	55	0~-0.012	h5	2
G8A600200308	R0.30	2	6	3	8	50	0~-0.012	h5	2
G8A600200310	R0.30	2	6	3	10	55	0~-0.012	h5	2
G8A600200312	R0.30	2	6	3	12	55	0~-0.012	h5	2
G8A600200316	R0.30	2	6	3	16	55	0~-0.012	h5	2
G8A60030	R0.50	3	6	4	10	55	0~-0.012	h5	2
G8A600300208	R0.20	3	6	4	8	55	0~-0.012	h5	2
G8A600300210	R0.20	3	6	4	10	55	0~-0.012	h5	2
G8A600300212	R0.20	3	6	4	12	55	0~-0.012	h5	2
G8A600300216	R0.20	3	6	4	16	55	0~-0.012	h5	2
G8A600300308	R0.30	3	6	4	8	55	0~-0.012	h5	2
G8A600300312	R0.30	3	6	4	12	55	0~-0.012	h5	2
G8A600300316	R0.30	3	6	4	16	55	0~-0.012	h5	2
G8A600300512	R0.50	3	6	4	12	55	0~-0.012	h5	2
G8A60040	R0.50	4	6	5	12	55	0~-0.012	h5	2
G8A600400212	R0.20	4	6	5	12	55	0~-0.012	h5	2
G8A600400216	R0.20	4	6	5	16	55	0~-0.012	h5	2
G8A600400220	R0.20	4	6	5	20	55	0~-0.012	h5	2
G8A600400310	R0.30	4	6	5	10	55	0~-0.012	h5	2
G8A600400316	R0.30	4	6	5	16	55	0~-0.012	h5	2
G8A600400320	R0.30	4	6	5	20	55	0~-0.012	h5	2
G8A600401012	R1.0	4	6	5	12	55	0~-0.012	h5	2
G8A600401016	R1.0	4	6	5	16	55	0~-0.012	h5	2
G8A60060	R0.50	6	6	7	20	60	0~-0.012	h5	2
G8A600602020	R2.0	6	6	7	20	60	0~-0.012	h5	2
G8A60080	R1.0	8	8	9	25	60	0~-0.015	h5	2
G8A600802025	R2.0	8	8	9	25	60	0~-0.015	h5	2
G8A60100	R1.0	10	10	11	32	70	0~-0.015	h5	2
G8A601000532	R0.50	10	10	11	32	70	0~-0.015	h5	2
G8A601002032	R2.0	10	10	11	32	70	0~-0.015	h5	2
G8A60120	R1.0	12	12	12	38	80	0~-0.015	h5	2
G8A601200538	R0.50	12	12	12	38	80	0~-0.015	h5	2
G8A601202038	R2.0	12	12	12	38	80	0~-0.015	h5	2
G8A60901	R0.50	3	6	4	16	55	0~-0.012	h5	2
G8A60902	R0.50	3	6	4	20	55	0~-0.012	h5	2
G8A60903	R0.50	4	6	5	16	55	0~-0.012	h5	2
G8A60904	R0.50	4	6	5	20	55	0~-0.012	h5	2
G8A60905	R1.0	6	6	7	20	60	0~-0.012	h5	2
G8A60906	R1.5	6	6	7	20	60	0~-0.012	h5	2
G8A60907	R1.5	8	8	9	25	60	0~-0.015	h5	2
G8A60908	R1.5	10	10	11	32	70	0~-0.015	h5	2
G8A60909	R1.5	12	12	12	38	80	0~-0.015	h5	2
G8A60910	R0.20	1	6	1.5	6	50	0~-0.012	h5	2
G8A60911	R0.20	1	6	1.5	8	50	0~-0.012	h5	2
G8A60912	R0.30	1	6	1.5	4	50	0~-0.012	h5	2
G8A60913	R0.20	1.5	6	2.5	10	50	0~-0.012	h5	2
G8A60914	R0.20	1.5	6	2.5	12	50	0~-0.012	h5	2
G8A60915	R0.30	1.5	6	2.5	4	50	0~-0.012	h5	2
G8A60916	R0.30	2	6	3	6	50	0~-0.012	h5	2
G8A60917	R0.50	2	6	3	6	50	0~-0.012	h5	2
G8A60918	R0.50	2	6	3	12	55	0~-0.012	h5	2
G8A60919	R0.30	3	6	4	10	55	0~-0.012	h5	2
G8A60920	R0.30	4	6	5	12	55	0~-0.012	h5	2
G8A60921	R0.30	6	6	7	20	60	0~-0.012	h5	2
G8A60922	R0.30	8	8	9	25	60	0~-0.015	h5	2
G8A60923	R0.30	10	10	11	32	70	0~-0.015	h5	2
G8A60924	R0.10	0.8	4	1.2	6	45	0~-0.012	h5	2
G8A60925	R0.10	1	6	1.5	4	50	0~-0.012	h5	2
G8A60926	R0.10	1	6	1.5	6	50	0~-0.012	h5	2
G8A60927	R0.20	2	6	3	6	50	0~-0.012	h5	2
G8A60929	R0.50	8	8	9	25	60	0~-0.015	h5	2
G8A60930	R0.30	1	6	1.5	6	50	0~-0.012	h5	2
G8A60931	R0.05	0.6	4	0.9	2	45	0~-0.012	h5	2
G8A60932	R0.05	0.5	4	0.7	2.5	45	0~-0.012	h5	2
G8A60933	R0.05	0.6	4	0.9	3	45	0~-0.012	h5	2
G8A60934	R0.05	0.6	4	0.9	4	45	0~-0.012	h5	2
G8A60935	R0.05	0.5	4	0.7	4	45	0~-0.012	h5	2
G8A60936	R0.05	0.5	4	0.7	1.5	45	0~-0.012	h5	2

Yêu cầu báo giá

Yêu cầu hỗ trợ báo giá nhanh, khách hàng vui lòng liên hệ Hotline 0902 59 13 12

Rất tiếc ! Sản phẩm này chưa có Video giới thiệu.
